Hammer Crusher for Metal

Features

This machine do the size reduction for the metal materials by friction, shearing, and collision.

The hammers rotating at high speed, generating impact energy.

Working Principle

1.   The motor drives the rotor at high speed through pulleys. Under centrifugal force, the hammers swing fully outward, forming a high-speed striking surface.

2.   Once the material enters the crushing chamber, it is instantly fractured by the impact of the high-speed hammers, then thrown against the toothed liner plates on the chamber wall and rebounded, where it is struck again by the hammers.

3.   Material with a particle size smaller than the screen openings is rapidly discharged through the screen under the combined effect of centrifugal force and airflow; larger particles remain inside the chamber for continuous circulation and crushing until they meet the required particle size, at which point they are discharged.

Models
