High-Speed Friction Washer

The Friction Washer is mainly composed of transmission assembly, screen assembly, bearing box, box support, power system and electrical control system. It is for the materials are not hardness enough,such as plastic film and tape fragments.

Impurities attached material surface and the material surface waste water will be cleaned and removed through high-speed centrifugal friction. Impurities and waste water will discharge through the screen hole, the box is equipped with automatic cleaning screen.

Features:
1-Spindle blade is made of 60Si2Mn, which is high strength, low noise, high efficiency.
2-Automatic overload protection.
3-The screen is interchangeable and easy to be replaced.

4-The box and screen are made of 304 stainless steel。

5-The legs have the anti-vibration device to improve the stability of the equipment。

6-Unique bearing housing design, can be configured with water circulation cooling, to prevent the bearing temperature is too high, damage to the bearing。

Specifications：
