The Waste Film Recycling Line can deal with industrial films, agriculture films, garbage films, PP woven bags, ton bags, etc. Materials will be processed by pre-shredding,pre-washing, crushing, friction washing, rinsing, centrifuging, and drying. After plastic film granulator crushing and cleaning, the film can be directly granulated or packaged for sale. And during the processing, it will not emit waste gas, and the wastewater can be reused too. Working Process 1. First, materials are sent to the Granulator to be shredded into sizes smaller than 90mm（could be customized）, allowing water to be contained during this process. 2. Then the shredded materials will be sent to the sink&floating Tank for washing the sediment off the surface.  3. Next the Friction Washer will rewash the material. 4. In order to make the materials cleaner, we will send the materials into the sink&floating tank for rinsing. 5. After rinsing, the materials will be sent to the Dewatering Machine for drying and the moisture content will be less than 5%. 6. The entire line is automated. It's secure, stable, and dependable. Granualtor  shreds the materials into sizes smaller than 90mm(the size could be customized） sink&floating Tank can wash the sediment off surface.  Friction Washer is for  washing the material agian. Dewatering Machine is used to dry the materials. Applications PP/PE Film Agricultural Waste Film Greenhouse Film  Woven Bags Land-filled Waste Film

The Waste Plastic Washing Line is capable of handling both WEEE and household plastic. Pre-shredding, pre-washing, crushing, friction washing, rinsing, centrifuging, and drying will process the material. Labels, dust, and other contamination will be removed, and you will get dry, clean, recyclable plastic. The entire system is simple to use, efficient, and has a low power consumption. Capacity ranges from 1 to 2 tons per hour. Working Process 1.Pre-crushing system will collect magnet metal out of large materials that have a little mount of metal. 2.It will crush the plastics into sizes smaller than 15mm, and it may contain water during the crushing process. 3.The sink material will be automatically collected, and the Trommel will send the floating material to the back. 4.The Friction Washer will remove the water and wash the material. 5.The Dewatering Machine will remove the water. 6.The Label Separator will collect fiber and light material. 7.The entire line is automated. It's secure, stable, and dependable. Applications Hard Plastics of All Types Plastics from Car Recycling Waste from Electrical Devices (WEEE) Containers and Barrels

The Waste Lithium-ion Battery Recycling System is designed to recycle waste lithium-ion batteries. The material will be processed by shredding, crushing, and separating, and the various components of the battery are sorted out into renewable materials. The whole system is easy to operate, efficient, and has low power consumption.  Applications Waste lithium-ion battery Soft pack battery Mobile phone battery Computer battery Power battery Lithium battery positive grade sheet Lithium battery negative grade sheet Lithium battery positive and negative grade sheet

The Waste Tire Recycling Line can handle the used tires. It recycles rubber, steel wire, and fiber from tires using a room temperature treatment process. It consists of a tire crusher, steel wire separator, disc sorting system, rubber crusher, miller, fiber sorting system, magnetic separator, screening equipment, dust collection system, cooling system, and automatic control system. We can tailor the solution to your specific needs. Capacity ranges from 1-20ton/hr. Rubber products 8-200 mesh. Working Process 1. Evenly conveyed tires into the Double Shaft Shredder. 2. The shredder can handle tire shreds as small as 80mm. 3. Tyre shreds larger than 80mm are returned to the shredder via the Back Feeding System. 4. Tyre shreds smaller than 80mm will be sent to the Rasper, where they will be crushed into materials smaller than 18mm. They will be filtered, yielding a mixture of rubber chips and waste steel wire. 5. It will separate the steel wire from the mixture using a Magnet Separator. The rubber chips will be crushed by a rubber Granulator. 6. High-speed rotors crush the rubber chips into 1-6mm rubber granules. 7. Different sizes of rubber granules and rubber powder will be separated. 8. The Miller will grind rubber granules into 20-80 mesh rubber powder. 9. It includes a dust collection system for dust, powder, and waste fiber. 10. The entire line is automated. It's secure, stable, and dependable. Tire shredder can shred scrap tires (small car tires, half wire tires, full wire tires, engineering tires,etc.)into 20-200mm rubber blocks, the size of rubber block can be adjusted to your requirements. There are two ways for feeding material--using conveyor or the grabbing  machine. The large volume tires can also be configured tire feeding pressure system to improve production efficiency. Tire Rasper is mainly used for scrap tire processing, the size of rubber block should be below 60mm. The rotor knives cut the rubber and steel wire away from the machine through medium speed rotation. Then we get the wire mixture of the rubber and waste steel below 12mm. With the subsequent processing process ,we can sort out rubber from waste steel wire. The rubber crusher can crush the rubber block into rubber particles below 6mm by rotating at high speed. Application Modified Asphalt Truck Tires Waterproof Materials Rubber Products Rubber Floor Tires Recycled Rubber Industry Contact us now to learn more details about our WASTE TIRE RECYCLING LINE !!!

The hazardous waste is corrosive, toxic, flammable, reactive, and infectious. If we don't deal with it properly, it will severely pollute the environment. The Hazardous Waste Container System can handle a hazardous waste metal container; the material will be processed through shredding, magnetization, crushing, washing, and drying; hazardous residue and other contamination will be removed; and you will get dry, clean, renewable steel scraps. The entire system is simple to use, efficient, and has a low power consumption. Capacity ranges from 1 to 5 tons per hour. Working Process: 1.The Pre-crushing system will shred the plastic and hazardous metal containers and wash them. 2.The Crushing system will crush the plastics into sizes smaller than 15mm, and it may contain water during the crushing process. Water is used to clean the material and put out the fire. 3.The Agglomerator will combine metal pieces and remove impurities. 4.The Trommel washer will remove any remaining impurities and oil. 5.The high-speed dewatering machine will remove the water by centrifuging. 6.The Detection system is for detecting fire. It will flush water or extinguish the fire with Nitrogen if there is the fire. 7.The entire line is automated. It's secure, stable, and dependable. Applications 200L oil drums Paint drums Chemical drums Ink drums Ton drums

A PET bottle recycling line is a specialized facility designed to process and recycle water bottle,sprite bottle, cola bottle, juice bottle, pet sheet, PET packing container, PET strap,PET film and so on. This line turns dirty bales of PET bottles into clean PET flakes ready for usage in producing polyester staple fiber or further processing into plastic granules via pelletizing.  Working Process: 1:Move off the label through our label remover; 2:The hopper will collect the labels by the wind; 3:The bottle without labels will be sent to our granulator for shredding into flakes or small pieces. 4:Then these PET-crushed materials will go to the high-speed friction washer for washing. 5:There are two sink floating tanks to separate the sand or dirt, and the leftover plastic films from labels and PP/PE bottle caps will float on water too. 6:The dewatering machine uses centrifugal force to remove a portion of the water from the PET flakes and make the final moisture content less than 3%.
